Design available to download on Cults3d – Click Here

This comprehensive design package includes all the necessary CAD files to create a scaled-down C172 instrument panel. Perfect for those with limited space, this design features:

Both Versions of the G1000 V1 & V2
Both Versions of the GMA 1347 Audio Panel
Both Versions of the Throttle (linear and rotary pot)
Mix Lever
Lower Fuse Panel
Dummy Standby Instruments
ELT Panel
AV Panel
Flaps Lever

Please note:
This instrument panel design is not full-size and has been adjusted to fit smaller spaces.
DXF or STL files are not included.
To access these files, you will need Fusion 360 or a similar CAD program.
